Cummins 100KVA Diesel Generator KCC-100GF 3-Phase 50HZ 400/230V
Cummins 100KVA Diesel Generator KCC-100GF 3-Phase 50HZ 400/230V
Genuine Cummins 100kVA diesel generator KCC-100GF, 50Hz 400/230V 3-phase. Powered by the 6-cylinder 6BT5.9-G2 engine, delivering 80kW prime and 115kVA standby output. 5.9L displacement with 207g/kWh fuel consumption.
- • Upgraded 6-Cylinder Cummins 6BT5.9-G2 Engine
- • Superior 5.9L Displacement for Sustained Power
- • High-Performance Cooling System for Extended Duty
- • Robust Heavy-Duty Steel Skid Base
- • Proven Global Service Network & Spare Parts Support
Cummins 100kVA Diesel Generator Set – KCC-100GF (50Hz, 3-Phase)
The KCC-100GF is a robust, mid-range power solution built around the globally renowned Cummins 6BT5.9-G2 diesel engine. Featuring a 6-cylinder, 5.9-liter inline design, this generator set delivers a prime power output of 80kW (100kVA) and a standby power output of 92kW (115kVA) at 50Hz, 400/230V, 3-phase.
Core Technical Specifications:
Engine Model: Cummins 6BT5.9-G2, 4-stroke, water-cooled, turbocharged with charge-air cooling.
Displacement: 5.9L, renowned for its balanced torque delivery and excellent transient load response.
Fuel Consumption: Rated at 207g/kWh at prime power, maintaining excellent fuel efficiency despite the larger displacement.
Construction: Heavy-duty welded steel skid base with integrated anti-vibration mounts, ensuring structural stability and reduced wear on engine components.
Control System: Advanced digital control panel with multi-language support, providing real-time monitoring of critical parameters and full protection against overload, low oil pressure, high water temperature, and overspeed.
Engineered for durability and long service life, the KCC-100GF combines Cummins' advanced combustion technology with a field-proven 6-cylinder platform, delivering reliable, efficient, and stable power for demanding industrial operations.
Supporting Services (Configuration Services)
Pre-sales Service
- We can provide environmental adaptation solutions for extreme cold, high temperature, salt spray, etc. for you to choose from
- Assist in coordinating local voltage, frequency, and grid connection requirements
- Can provide capacity assessment and reference suggestions for data center layout
In-sales Service
- Conduct a full load test before leaving the factory and provide a test report
- Adopting moisture-proof and shockproof packaging, suitable for sea transportation
- Can synchronize production progress and provide customs clearance documents along with the goods
After-sales Service
- Provide technical consultation and remote guidance during working hours
- Partial areas have spare parts reserves, which can shorten the supply cycle
- Provide basic operation training materials and arrange online explanations as needed
Application Areas
- Infrastructure: Industrial and mining enterprises, real estate developments, road and bridge construction sites
- Public Services: Hospitals, schools, postal and telecommunications facilities, fire departments
- Specialized Scenarios: Forest and pasture areas, military units, and any locations requiring highly reliable power supply
