Shangchai generator set
If this product cannot meet your specific power needs, you can check our other diesel generator sets or submit personalized power requirements to us. Our power engineers will contact you within 24 hours for customization.
β‘ In Stock
Shangchai generator set
Power Range
20-2000kVA
Fuel Type
Diesel
Warranty
1 Year / 1000 Hours
Shangchai 20-1118kVA diesel genset. H/D/E/G/W series. Open, silent, trailer. 6135 historic engine. Ideal for marine, factory, farm, telecom.
- β’ Compact structure with reasonable dimensions, saving installation space.
- β’ Low fuel and oil consumption rates for reduced operating costs.
- β’ Large market presence with stable parts supply channels and convenient maintenance.
- β’ Turbocharged design with minimal power derating in high-altitude conditions.
- β’ Reliable starting performance across a wide ambient temperature range.
Shangchai KC genset 50HZ/60HZ
| 50HZ | ||||||
| Genset Model | Standby Power | Prime Power | Engine Model | L*W*H (mm) | ||
| KVA | KW | KVA | KW | |||
| KC-S28 | 28 | 22 | 25 | 20 | 4H4.3-G21 | 1800*820*1250 |
| KC-S44 | 44 | 35 | 40 | 32 | 4H4.3-G22 | 1800*820*1250 |
| KC-S55 | 55 | 44 | 50 | 40 | 4HT4.3-G21 | 1850*820*1300 |
| KC-S88 | 88 | 70 | 80 | 64 | 4HT4.3-G23 | 1800*820*1300 |
| KC-S116 | 116 | 92 | 105 | 84 | 4HTAA4.3-G21 | 2170*880*1400 |
| KC-S135 | 135 | 108 | 125 | 100 | 4HTAA4.3-G22 | 2170*880*1600 |
| KC-S151 | 151 | 121 | 138 | 110 | 6HTAA6.5-G21 | 2170*880*1400 |
| KC-S161 | 161 | 129 | 150 | 120 | 6HTAA6.5-G22 | 2170*880*1400 |
| KC-S202 | 202 | 162 | 188 | 150 | 6HTAA6.5-G23 | 2350*950*1600 |
| KC-S220 | 220 | 176 | 200 | 160 | 6DTAA8.9-G21 | 2550*980*1600 |
| KC-S275A | 275 | 220 | 250 | 200 | 6DTAA8.9-G22 | 2550*980*1650 |
| KC-S275B | 275 | 220 | 250 | 200 | 6DTAA8.9-G23 | 2550*980*1650 |
| KC-S385 | 385 | 308 | 350 | 280 | 6ETAA11.8-G21 | 3150*1100*1850 |
| KC-S438 | 438 | 350 | 400 | 320 | 6ETAA12.8-G32 | 3150*1100*1850 |
| KC-S500 | 500 | 400 | 438 | 350 | 6ETAA12.8-G31 | 3150*1100*1850 |
| KC-S385 | 385 | 308 | 350 | 280 | 6ETAA11.8-G33 | 3150*1100*1850 |
| KC-S413 | 413 | 330 | 375 | 300 | 6ETAA11.8-G31 | 3150*1100*1850 |
| KC-S563 | 563 | 450 | 500 | 400 | 6ETAA12.8-G310 | 3600*1690*2120 |
| KC-S625 | 625 | 500 | 500 | 450 | 6KTAA25-G35 | 3550*1400*2000 |
| KC-S688 | 688 | 550 | 625 | 500 | 6KTAA25-G34 | 3600*1690*2100 |
| KC-S750 | 750 | 600 | 688 | 550 | 6KTAA25-G33 | 3900*1800*2200 |
| KC-S825 | 825 | 660 | 750 | 600 | 6KTAA25-G32 | 3900*1800*2200 |
| KC-S875 | 875 | 700 | 800 | 640 | 6KTAA25-G31 | 4200*1800*2200 |
| KC-S1000 | 1000 | 800 | 900 | 720 | 6WTAA35-G32 | 4300*1800*2300 |
| KC-S1100 | 1100 | 880 | 1000 | 800 | 6WTAA35-G31 | 4300*1800*2300 |
| KC-S1250 | 1250 | 1000 | 1125 | 900 | 6WTAA35-G310 | 4400*1800*2400 |
| KC-S1375 | 1375 | 1100 | 1250 | 1000 | 6WTAA35-G311 | 4500*1900*2400 |
| KC-S1563 | 1563 | 1250 | 1375 | 1100 | 12KTA58-G36 | 4500*1900*2400 |
| KC-S1688 | 1688 | 1350 | 1500 | 1200 | 12KTA58-G35 | 4600*2000*2400 |
| KC-S1875 | 1875 | 1500 | 1688 | 1350 | 12KTA58-G34 | 4700*1000*2400 |
| KC-S1938 | 1938 | 1550 | 1750 | 1400 | 12KTA58-G33 | 4800*2000*2400 |
| KC-S2000 | 2000 | 1600 | 1875 | 1500 | 12KTA58-G32 | 4800*2000*2400 |
| KC-S2250 | 2250 | 1800 | 2125 | 1700 | 12KTA58-G31 | 5000*2000*2400 |
| KC-SH69 | 69 | 55 | 63 | 50 | SC4H95D2 | 2000*850*1400 |
| KC-SH88 | 88 | 70 | 80 | 64 | SC4H115D2 | 2000*800*1360 |
| KC-SH124 | 124 | 99 | 113 | 90 | SC4H160D2 | 2000*920*1450 |
| KC-SH135 | 135 | 108 | 125 | 100 | SC4H180D2 | 2000*920*1435 |
| KC-SH186 | 186 | 149 | 169 | 135 | SC7H230D2 | 2580*950*1600 |
| KC-SH202 | 202 | 162 | 188 | 150 | SC7H250D2 | 2500*990*1600 |
| KC-SH227 | 227 | 182 | 206 | 165 | SC8D280D2 | 2600*1000*1750 |
| KC-SH248 | 248 | 198 | 225 | 180 | SC9D310D2 | 2600*1000*1700 |
| KC-SH275 | 275 | 220 | 250 | 200 | SC9D340D2 | 2600*950*1600 |
| KC-SH385 | 385 | 308 | 350 | 280 | SC12E460D2 | 3200*1100*1750 |
| KC-SH413 | 413 | 330 | 375 | 300 | SC15G500D2 | 3200*1250*1850 |
| KC-SH495 | 495 | 396 | 450 | 360 | SC25G610D2 | 3550*1400*2000 |
| KC-SH550 | 550 | 440 | 500 | 400 | SC25G690D2 | 3600*1700*2150 |
| KC-SH615 | 615 | 492 | 563 | 450 | SC27G755D2 | 3550*1400*2000 |
| KC-SH680 | 680 | 544 | 625 | 500 | SC27G830D2 | 3600*1700*2100 |
| KC-SH825 | 825 | 660 | 750 | 600 | SC33W990D2 | 4400*1800*2300 |
| KC-SH990 | 990 | 792 | 900 | 720 | SC33W1150D2 | 4400*1800*2300 |
| 60HZ | ||||||
| Genset Model | Standby Power | Prime Power | Engine Model | L*W*H (mm) | ||
| KVA | KW | KVA | KW | |||
| KC-SC34 | 34 | 28 | 31 | 25 | 4H4.3-G21 | 1800*820*1247 |
| KC-SC55 | 55 | 44 | 50 | 40 | 4H4.3-G22 | 1800*820*1247 |
| KC-SC93 | 93 | 74 | 85 | 68 | 4HT4.3-G23 | 2170*880*1278 |
| KC-SC124 | 124 | 99 | 113 | 90 | 4HTAA4.3-G21 | 2170*880*1359 |
| KC-SC138 | 138 | 110 | 125 | 100 | 4HTAA4.3-G22 | 2170*880*1392 |
| KC-SC165 | 165 | 132 | 150 | 120 | 6HTAA6.5-G21 | 2170*880*1397 |
| KC-SC175 | 175 | 140 | 160 | 128 | 6HTAA6.5-G22 | 2170*880*1397 |
| KC-SC227 | 227 | 182 | 206 | 165 | 6HTAA6.5-G23 | 2350*950*1570 |
| KC-SC250 | 250 | 200 | 228 | 182 | 6DTAA8.9-G21 | 2550*980*1582 |
| KC-SC289 | 289 | 231 | 263 | 210 | 6DTAA8.9-G22 | 2550*980*1650 |
| KC-SC300 | 300 | 240 | 275 | 220 | 6DTAA8.9-G23 | 2550*980*1650 |
| KC-SC385 | 385 | 308 | 350 | 280 | 6ETAA11.8-G21 | 3150*1100*1825 |
| KC-SC405 | 405 | 323 | 368 | 294 | 6ETAA11.8-G31 | 3150*1100*1825 |
β Swipe to view full table
Supporting Services (Configuration Services)
Pre-sales Service
- We can provide environmental adaptation solutions for extreme cold, high temperature, salt spray, etc. for you to choose from
- Assist in coordinating local voltage, frequency, and grid connection requirements
- Can provide capacity assessment and reference suggestions for data center layout
In-sales Service
- Conduct a full load test before leaving the factory and provide a test report
- Adopting moisture-proof and shockproof packaging, suitable for sea transportation
- Can synchronize production progress and provide customs clearance documents along with the goods
After-sales Service
- Provide technical consultation and remote guidance during working hours
- Partial areas have spare parts reserves, which can shorten the supply cycle
- Provide basic operation training materials and arrange online explanations as needed
Application Areas
- Infrastructure: Industrial and mining enterprises, real estate developments, road and bridge construction sites
- Public Services: Hospitals, schools, postal and telecommunications facilities, fire departments
- Specialized Scenarios: Forest and pasture areas, military units, and any locations requiring highly reliable power supply
Model
Shangchai generator set
Power Range
20-2000kVA
Fuel Type
Diesel
Frequency
50/60 Hz
Voltage
220V / 380V / 415V / Custom
Cooling System
Water-cooled / Air-cooled
Control System
Automatic / Manual / Remote
