18KVA DOOSAN Diesel Generator KCD-20GF
18KVA DOOSAN Diesel Generator KCD-20GF
Genuine DOOSAN 18kVA diesel generator KCD-20GF, 50Hz 400/230V 3-phase, powered by a 4-cylinder SP224NA 2.2L engine delivering 14kW prime and 15kW standby output, featuring mechanical governor and compact design for reliable small-scale power applications.
- • Efficient Mechanical Governor for Reliable Frequency Control
- • Compact Footprint for Space-Limited Installations
- • Simplified Maintenance with Direct Access Points
- • Robust 4-Cylinder Layout with High Structural Rigidity
- • Larger 2.2L Displacement for Steady Power Delivery
DOOSAN 18kVA Diesel Generator Set – KCD-20GF (50Hz, 3-Phase)
The KCD-20GF is a durable generator set built around the DOOSAN SP224NA diesel engine. Featuring a 4-cylinder, 2.2-liter inline configuration, this unit delivers a prime power output of 14kW (18kVA) and a standby power output of 15kW (20kVA) at 50Hz, 400/230V, 3-phase.
Core Technical Specifications:
Engine Model: DOOSAN SP224NA, 4-stroke, water-cooled, naturally aspirated.
Displacement: 2.2L, providing consistent torque for stable operation under varying loads.
Governor Type: Mechanical governor, offering simple and reliable speed control.
Physical Dimensions: 1500mm (L) × 750mm (W) × 1030mm (H) – designed for space-efficient installation.
Cooling System: Closed-circuit water cooling with a fan-assisted radiator.
Control System: Digital control panel with basic protection features, including low oil pressure and high coolant temperature alarms.
Built with DOOSAN's reliable engineering and a practical layout, the KCD-20GF provides a dependable power source for small-scale commercial and industrial requirements.
Supporting Services (Configuration Services)
Pre-sales Service
- We can provide environmental adaptation solutions for extreme cold, high temperature, salt spray, etc. for you to choose from
- Assist in coordinating local voltage, frequency, and grid connection requirements
- Can provide capacity assessment and reference suggestions for data center layout
In-sales Service
- Conduct a full load test before leaving the factory and provide a test report
- Adopting moisture-proof and shockproof packaging, suitable for sea transportation
- Can synchronize production progress and provide customs clearance documents along with the goods
After-sales Service
- Provide technical consultation and remote guidance during working hours
- Partial areas have spare parts reserves, which can shorten the supply cycle
- Provide basic operation training materials and arrange online explanations as needed
Application Areas
- Infrastructure: Industrial and mining enterprises, real estate developments, road and bridge construction sites
- Public Services: Hospitals, schools, postal and telecommunications facilities, fire departments
- Specialized Scenarios: Forest and pasture areas, military units, and any locations requiring highly reliable power supply
