38KVA DOOSAN Diesel Generator KCD-40GF
38KVA DOOSAN Diesel Generator KCD-40GF
Genuine DOOSAN 38kVA diesel generator KCD-40GF, 50Hz 400/230V 3-phase, powered by an ECU-governed SP244CA 2.392L engine delivering 33kW prime and 30kW standby output, featuring enhanced cooling and precise frequency control for stable industrial power applications.
- • Upgraded 2.392L Displacement with Reinforced Structure
- • Stable Frequency Response Under Variable Loads
- • Spacious 1700mm Footprint for Enhanced Cooling & Service
- • Robust 33kW Prime Output for Medium Small Loads
- • Advanced ECU Electronic Governor for Precision Control
DOOSAN 38kVA Diesel Generator Set – KCD-40GF (50Hz, 3-Phase)
The KCD-40GF is a reliable generator set powered by the DOOSAN SP244CA diesel engine. Featuring a 4-cylinder, 2.392-liter inline configuration with electronic governing, this unit delivers a prime power output of 26kW (33kVA) and a standby power output of 30kW (38kVA) at 50Hz, 400/230V, 3-phase.
Core Technical Specifications:
Engine Model: DOOSAN SP244CA, 4-stroke, water-cooled, turbocharged with charge-air cooling.
Displacement: 2.392L, designed for consistent torque delivery and quick load acceptance.
Governor Type: Electronic governor (ECU), providing precise speed regulation and rapid transient response.
Physical Dimensions: 1700mm (L) × 750mm (W) × 1150mm (H) – designed for efficient installation and ventilation.
Cooling System: Closed-circuit water cooling with a large-capacity radiator, suitable for continuous operation.
Control System: Digital control panel with real-time monitoring and comprehensive protection features, including low oil pressure, high coolant temperature, and overload shutdown.
Built with DOOSAN's advanced electronic control and enhanced platform, the KCD-40GF delivers stable, efficient, and reliable power for commercial and light industrial applications requiring precise frequency management.
Supporting Services (Configuration Services)
Pre-sales Service
- We can provide environmental adaptation solutions for extreme cold, high temperature, salt spray, etc. for you to choose from
- Assist in coordinating local voltage, frequency, and grid connection requirements
- Can provide capacity assessment and reference suggestions for data center layout
In-sales Service
- Conduct a full load test before leaving the factory and provide a test report
- Adopting moisture-proof and shockproof packaging, suitable for sea transportation
- Can synchronize production progress and provide customs clearance documents along with the goods
After-sales Service
- Provide technical consultation and remote guidance during working hours
- Partial areas have spare parts reserves, which can shorten the supply cycle
- Provide basic operation training materials and arrange online explanations as needed
Application Areas
- Infrastructure: Industrial and mining enterprises, real estate developments, road and bridge construction sites
- Public Services: Hospitals, schools, postal and telecommunications facilities, fire departments
- Specialized Scenarios: Forest and pasture areas, military units, and any locations requiring highly reliable power supply
Ready to Power Your Business?
Get a customized quote for your power generation needs today.
