81KVA DOOSAN Diesel Generator KCD-90GF
81KVA DOOSAN Diesel Generator KCD-90GF
Genuine DOOSAN 81kVA diesel generator KCD-90GF, 50Hz 400/230V 3-phase, powered by a common rail SP344CC 3.4L engine delivering 65kW prime and 72kW standby output, featuring G3 governor class and 16.8:1 compression ratio for efficient, stable industrial power supply.
- • Advanced Common Rail Injection System with 1800bar Pressure
- • Environmentally Friendly Emission Compliance (Stage IIIA)
- • Reliable 65kW Prime Output with Turbo & Intercooler
- • G3 Governor Class for Precision Frequency Regulation
- • High 16.8:1 Compression Ratio for Efficient Combustion
DOOSAN 81kVA Diesel Generator Set – KCD-90GF (50Hz, 3-Phase)
The KCD-90GF is a high-efficiency generator set powered by the DOOSAN SP344CC diesel engine. Featuring a 4-cylinder, 3.4-liter inline configuration with Bosch 1800bar common rail direct injection and turbocharging with intercooling, this unit delivers a prime power output of 65kW (81kVA) and a standby power output of 72kW (90kVA) at 50Hz, 400/230V, 3-phase.
Core Technical Specifications:
Engine Model: DOOSAN SP344CC, 4-stroke, water-cooled, turbocharged with charge-air cooling
Displacement: 3.4L, with a 16.8:1 compression ratio for efficient combustion
Fuel System: High-pressure common rail injection, achieving a fuel consumption rate of approximately 18.1 L/H at full prime load
Governor Type: Electronic governor (ECM), meeting G3 governing class standards
Cooling System: Closed-circuit water cooling with a large-capacity radiator, designed for continuous operation in ambient temperatures up to 52°C
Control System: Digital control panel with real-time monitoring and comprehensive protection against low oil pressure, high coolant temperature, and overload conditions
Built with DOOSAN's advanced common rail technology, the KCD-90GF provides stable, efficient, and environmentally conscious power for commercial and industrial applications.
Supporting Services (Configuration Services)
Pre-sales Service
- We can provide environmental adaptation solutions for extreme cold, high temperature, salt spray, etc. for you to choose from
- Assist in coordinating local voltage, frequency, and grid connection requirements
- Can provide capacity assessment and reference suggestions for data center layout
In-sales Service
- Conduct a full load test before leaving the factory and provide a test report
- Adopting moisture-proof and shockproof packaging, suitable for sea transportation
- Can synchronize production progress and provide customs clearance documents along with the goods
After-sales Service
- Provide technical consultation and remote guidance during working hours
- Partial areas have spare parts reserves, which can shorten the supply cycle
- Provide basic operation training materials and arrange online explanations as needed
Application Areas
- Infrastructure: Industrial and mining enterprises, real estate developments, road and bridge construction sites
- Public Services: Hospitals, schools, postal and telecommunications facilities, fire departments
- Specialized Scenarios: Forest and pasture areas, military units, and any locations requiring highly reliable power supply
