50KVA DOOSAN Diesel Generator KCD-55GF
50KVA DOOSAN Diesel Generator KCD-55GF
Genuine DOOSAN 50kVA diesel generator KCD-55GF, 50Hz 400/230V 3-phase, powered by a 6-cylinder SP344CA 3.44L engine delivering 40kW prime and 44kW standby output, featuring strong sudden load acceptance and compact design for reliable commercial power applications.
- • Strong Sudden Load Acceptance Capability
- • Compact 6-Cylinder Design for Space Efficiency
- • Upgraded 6-Cylinder DOOSAN SP344CA Engine
- • Larger 3.44L Displacement for Robust Torque Delivery
- • Simplified Service Access for Routine Maintenance
DOOSAN 50kVA Diesel Generator Set – KCD-55GF (50Hz, 3-Phase)
The KCD-55GF is a robust generator set built around the DOOSAN SP344CA diesel engine. Featuring a 6-cylinder, 3.44-liter inline configuration, this unit delivers a prime power output of 40kW (50kVA) and a standby power output of 44kW (55kVA) at 50Hz, 400/230V, 3-phase.
Core Technical Specifications:
Engine Model: DOOSAN SP344CA, 4-stroke, water-cooled, naturally aspirated.
Displacement: 3.44L, providing enhanced torque characteristics and stable operation under varying loads.
Governor Type: Mechanical governor, offering reliable speed control.
Physical Dimensions: 1850mm (L) × 800mm (W) × 1180mm (H) (based on catalog data for this series).
Cooling System: Closed-circuit water cooling with a fan-assisted radiator.
Control System: Digital control panel with basic protection features, including low oil pressure and high coolant temperature alarms.
Built with DOOSAN's reliable engineering and a practical layout, the KCD-55GF provides a dependable power source for small-to-medium commercial and industrial requirements.
Supporting Services (Configuration Services)
Pre-sales Service
- We can provide environmental adaptation solutions for extreme cold, high temperature, salt spray, etc. for you to choose from
- Assist in coordinating local voltage, frequency, and grid connection requirements
- Can provide capacity assessment and reference suggestions for data center layout
In-sales Service
- Conduct a full load test before leaving the factory and provide a test report
- Adopting moisture-proof and shockproof packaging, suitable for sea transportation
- Can synchronize production progress and provide customs clearance documents along with the goods
After-sales Service
- Provide technical consultation and remote guidance during working hours
- Partial areas have spare parts reserves, which can shorten the supply cycle
- Provide basic operation training materials and arrange online explanations as needed
Application Areas
- Infrastructure: Industrial and mining enterprises, real estate developments, road and bridge construction sites
- Public Services: Hospitals, schools, postal and telecommunications facilities, fire departments
- Specialized Scenarios: Forest and pasture areas, military units, and any locations requiring highly reliable power supply
