63KVA DOOSAN Diesel Generator KCD-70GF
63KVA DOOSAN Diesel Generator KCD-70GF
Genuine DOOSAN 63kVA diesel generator KCD-70GF, 50Hz 400/230V 3-phase, powered by a common rail turbocharged SP344CB 3.4L engine delivering 50kW prime and 55kW standby output, featuring strong sudden load acceptance and compact design for reliable industrial power applications.
- • Common Rail Direct Injection System for Fuel Efficiency
- • Compact 4-Cylinder Layout for Space Efficiency
- • Replaceable Cylinder Liners for Extended Service Life
- • Turbocharged 3.4L Engine for Enhanced Power Density
- • Strong Sudden Load Acceptance for Critical Operations
DOOSAN 63kVA Diesel Generator Set – KCD-70GF (50Hz, 3-Phase)
The KCD-70GF is a reliable generator set powered by the DOOSAN SP344CB diesel engine. Featuring a 4-cylinder, 3.4-liter inline configuration with common rail direct injection and turbocharging, this unit delivers a prime power output of 50kW (63kVA) and a standby power output of 55kW (69kVA) at 50Hz, 400/230V, 3-phase.
Core Technical Specifications:
Engine Model: DOOSAN SP344CB, 4-stroke, water-cooled, turbocharged with charge-air cooling
Displacement: 3.4 liters, providing consistent torque for stable operation under varying loads
Governor Type: Mechanical governor, offering reliable speed control
Physical Dimensions: 1850mm (L) × 800mm (W) × 1180mm (H) (based on catalog data)
Cooling System: Closed-circuit water cooling with a fan-assisted radiator
Control System: Digital control panel with comprehensive protection features, including low oil pressure, high coolant temperature, and overload shutdown
Built with DOOSAN's proven engine technology, the KCD-70GF delivers stable, efficient, and reliable power for medium-scale commercial and industrial applications.
Supporting Services (Configuration Services)
Pre-sales Service
- We can provide environmental adaptation solutions for extreme cold, high temperature, salt spray, etc. for you to choose from
- Assist in coordinating local voltage, frequency, and grid connection requirements
- Can provide capacity assessment and reference suggestions for data center layout
In-sales Service
- Conduct a full load test before leaving the factory and provide a test report
- Adopting moisture-proof and shockproof packaging, suitable for sea transportation
- Can synchronize production progress and provide customs clearance documents along with the goods
After-sales Service
- Provide technical consultation and remote guidance during working hours
- Partial areas have spare parts reserves, which can shorten the supply cycle
- Provide basic operation training materials and arrange online explanations as needed
Application Areas
- Infrastructure: Industrial and mining enterprises, real estate developments, road and bridge construction sites
- Public Services: Hospitals, schools, postal and telecommunications facilities, fire departments
- Specialized Scenarios: Forest and pasture areas, military units, and any locations requiring highly reliable power supply
